Application:handle petroleum products up to 50% aromatics on marine docks ,ships, and barges.
Characteristics: flexible; abrasion, aging, oil, weather, ozone resistance
Working temperature: -20 TO 120 ℃
Delivery cycle: As your order(2000 meters per day).
Type of shipping: Tianjin port or Qingdao port.
Safety factor: 1:3
Notes: Not bend over bending diameter ,not squeeze over, Avoid colliding flange surface.
Technical parameters:
Hose lining: NBR
Reinforcement layer: tire cord with helix wire
Cover rubber layer: CR and NBR blend
ID | OD | Length | Bend radium | WP | Weight | |||||
in | mm | in | mm | ft | m | in | mm | Psi | Kg/cm² | Kg/m |
2 | 50.8 | 2.575 | 65.4 | 66-200 | 20-60 | 12 | 300 | 225 | 15 | 1.84 |
2 1/2 | 63.5 | 3.217 | 81.7 | 66-200 | 20-60 | 16 | 400 | 225 | 15 | 2.8 |
3 | 76.2 | 3.764 | 95.6 | 66-200 | 20-60 | 18 | 450 | 225 | 15 | 3.48 |
4 | 101.6 | 4.803 | 122 | 66-200 | 20-60 | 24 | 600 | 225 | 15 | 4.74 |
5 | 127 | 5.945 | 151 | 66-200 | 20-60 | 30 | 750 | 225 | 15 | 6.85 |
6 | 152.4 | 6.976 | 177.2 | 66-200 | 20-60 | 36 | 900 | 225 | 15 | 8.33 |
8 | 203.2 | 9.197 | 233.6 | 66-200 | 20-60 | 48 | 1200 | 225 | 15 | 13.51 |
10 | 254 | 11.433 | 290.4 | 33-100 | 20-60 | 60 | 1500 | 225 | 15 | 19.31 |
12 | 304.8 | 13.638 | 346.4 | 33-100 | 20-60 | 72 | 1800 | 225 | 15 | 26.36 |
